HSD-五轴头HS560 + ES779定金

参数

ELECTROHEAD DATA

Standard Servomotors: Yaskawa, Num, Siemens, Beckhoff

A Axis stall / max torque: 300Nm; 600Nm

C Axis stall / max torque C: 400Nm; 800Nm

Clamping torque Axes brakes A; C: /

Max speed Axes A; C: 80° sec ; 80° sec

Axis positioning accuracy: 60 arcsec; 60 arcsec

A Axes rotation ENDLESS

C Axes rotation ±245°

C Axes endless rotation (Slip Ring): option

A Axes endless rotation (Slip Ring): Yes

Direct Axis encoder: no

Axes Brakes: no

Weight: ~120kg

SPINDLES DATA

Available electrospindle ES779 liquid

Taper HSK F63

Power S1-S6 10kW / 12kW Asynchronous

Max Torque S1-S6 12,7Nm / 15,3Nm Asynchronous

Power S1-S6 13,5kW / 16,2kW Asynchronous

Max Torque S1-S6 10,7Nm / 12,9Nm Asynchronous

Max RPM 24.000

Rated RPM: 7.500 / 12.000

Spindle encoder: option (TTL)

OTHER AVAILABLE SPINDLES

ES362 HSK F63 Asyn.

12kW / 15kW - 22.000 - no encoder
